| Name | JPG | DXF |
| Full name | JPG - Joint Photographic Experts Group | DXF - Drawing Interchange Format |
| File extension | .jpg, .jpeg, .jpe | .dxf |
| MIME type | image/jpeg | image/vnd.dxf |
| Developed by | Joint Photographic Experts Group | Autodesk |
| Type of format | lossy image format | CAD |
| Description | JPG is a commonly used method of lossy compression for digital images, particularly for those images produced by digital photography. The degree of compression can be adjusted, allowing a selectable tradeoff between storage size and image quality. JPG typically achieves 10:1 compression with little perceptible loss in image quality. | AutoCAD DXF (Drawing Interchange Format, or Drawing Exchange Format) is a CAD data file format developed by Autodesk for enabling data interoperability between AutoCAD and other programs. Versions of AutoCAD from Release 10 and up support both ASCII and binary forms of DXF. Earlier versions support only ASCII. |
| Technical details | Image files that employ JPG compression are commonly called 'JPG files', and are stored in variants of the JIF image format. Most image capture devices (such as digital cameras) that output JPG are actually creating files in the Exif format, the format that the camera industry has standardized on for metadata interchange. | As AutoCAD has become more powerful, supporting more complex object types, DXF has become less useful. Certain object types, including ACIS solids and regions, are not documented. DXF coordinates are always without dimensions so that the reader or user needs to know the drawing unit or has to extract it from the textual comments in the sheets. |
| File conversion | JPG conversion | DXF conversion |
| Associated programs | Apple Safari, Google Chrome, Mozilla Firefox, Internet Explorer, Adobe Photoshop, Paint Shop Pro, the GIMP, ImageMagick, IrfanView, Pixel image editor, Paint.NET, Xara Photo & Graphic Designer. | AutoCAD |
| Wiki | https://en.wikipedia.org/wiki/JPEG | https://en.wikipedia.org/wiki/AutoCAD_DXF |
Importing Gerber/DXF from PCB into SolidWorks As the design of PCB's becomes more complex, the need to do 3D modeling of a printed circuit board also becomes more important. Many PCB design tools have an interface to SolidWorks via the IDF file format - however this approach is useful mostly for components, connectors, board outline. Gerber PCB (printed circuit data) can be exported to several other CAD / engineering formats, including standard 2D DXF format. Most of the currently available / sold PCB programs should have this feature as default function, which should make gerber to dxf conversions pretty easy to achieve. Gerber2PDF is a command-line tool to convert Gerber files to PDF for proofing and hobbyist printing purposes. It converts multiple Gerber files at once, placing the resulting layers each on it's own page within the PDF. Each layer has a PDF bookmark for easy reference.
Gerber To Dxf Converter
DXF Conversion Secrets for Gerber, GDS-II, ODB, etc. FAB 3000 Version 6.5 to be released October 3rd, 2012; ACE Translator (Verison 7) EasyGerb 5 for AutoCAD Mechanical is here! EasyGerb 5 now supports AutoCAD 2013; Recent Comments; Archives. January 2013; September 2012; Categories. 3D Modeling; 3D) AutoCAD to Gerber; DFM Check; DXF to. Gerber To Dxf, free gerber to dxf software downloads. Aide PDF to DXF is a powerful windows program that will help you convert your PDF files to usable and editable DXF files quickly and easily. Convert thousands of PDF files to DXF files in one easy step. Batch convert all pages in each.
